Marine GPS Navigator 7inch (with SD-card Map Chart Sea)

$495.99 USD

~~$550.99 USD~~ $495.99 USD

Sale Sold out

Shipping calculated at checkout.

Default Title Default Title

Quantity

SPECIFICATIONS

Brand Name: ONWA

Screen Resolution: 480x272

Memory Size: 512M

Certification: CE

Certification: FCC

Operating System: RIM

Special Features: Charger

Model: KP -39

7inch ONWA LCD marine GPS Chart Plotter, Support K-chart and C-map SD card

Menu languages: support English, Spanish, French, German, Dutch, Italian, Portuguese, Vietnamese, Indonesian, Chinese, Thai, Arabic language and more。

gps nautico maritimo

gps nautico

Please leave a message on which area of the ocean map you would !

with SD-card Map (Note: Chart of which sea is required)

RECEIVER CHARACTERISTICS
1. RECEIVER TYPE	GPS : Twelve discrete channels, C/A code, all – in – view . SBAS receiver
2. RECEIVER FREQUENCY	L1 (1575.42MHz)
3. TIME TO FIRST FIX	15 seconds average (Hot start)
4. TRACKING VELOCITY	999 knots
5. GEODETIC SYSTEMS	WGS-84
ACCURACY
1. GPS	15m (95%)
2. SBAS	3m (95%)
DISPLAY UNIT
1. TYPE	4.5″ diagonal 95(W) x 63 (H) mm LCD, 240 x 160 pixels
2. DISPLAY MODES	Plotter, Highway, Steering, Speedometer, Nav Data and 2 pages Customizable display
3. MEMORY CAPACITY	2,500 ship's track points 999 waypoints with comments 50 routes, 30 waypoints/route
4. ALARMS	Arrival, Anchor watch, XTE, Speed, Time, Trip, Odometer
5. LANGUAGE	English, Spanish, French, German, Dutch, Italian, Portuguese, Vietnamese, Indonesian, Chinese, Thai
6. INTERFACE	Output ( NMEA0183 ver 2.0 ) AAM, APB, BOD, BWC, GGA, GLL, RMB, RMC, VTG, XTE, ZDA
ENVIRONMENT
1. TEMPERATURE	Display unit: -15 degrees Celsius to +55 degrees Celsius Antenna unit: -25 degrees Celsius to +70 degrees Celsius
2. WATERPROOFING	Display unit:IPX5 Antenna unit: IPX6
POWER SUPPLY
12-24 VDC, 240 -120mA
EQUIPMENT LIST
	Display unit accommodating SBAS receiver – 1 unit Antenna unit KA-07 with 10 m cable – 1 set Installation materials and spare parts – 1 set
